Industrial Pressure Transmitter Sensor WZP-231-PT100

Industrial Pressure Transmitter Sensor WZP-231-PT100 | Brand New |

Pressure Transmitter Sensor

Model: WZP-231

Thermal Resistor: PT100

Explore More Industrial Parts

Condition: Factory New Sealed

Availability: In Stock

Ships: Fast and Reliable Shipping

Brand New Without Warranty

Frequently Asked Questions (FAQs): PT100 WZP-231 Pressure Transmitter

1. What is the output signal of this pressure transmitter?

The PT100 WZP-231 offers a standard 2-wire, 4-20mA output signal. This is the most common analog signal in industrial application because it is extremely resistant to electrical noise and may be transmitted over long distances.

2. What pressure ranges are available?

We carry this transmitter in a wide variety of standard pressure ranges (e.g., 0-100 psi, 0-500 psi, 0-1000 psi, 0-5000 psi, etc.). See the range selector dropdown on the product page to see all choices. Custom ranges can also be made available upon request.

3. How precise is this sensor?

The standard accuracy is ±0.5% of the full-scale (F.S.) range. For instance, a 0-1000 PSI model would be accurate to ±5 PSI over its full range.

4. What fluids or media can it measure?

This transmitter is constructed with 316 stainless steel wetted parts and may be used with a wide range of media including oil, water, air, natural gas, hydraulic fluids, and many other non-clogging, non-corrosive liquids and gases. It should not be used with highly corrosive media such as chlorine or acids without modifying.

5. What is the process connection type and size?

The standard connection type is 1/2\\" NPT male thread. This is a very common thread size in North America. Other connection options like G1/2\\" (BSPP) or M20x1.5 are generally available.

6. What type of power supply does it require?

4-20mA output requires a DC power supply. Normal operating voltage is 12-36 VDC, and the most common standard in industry is 24 VDC.

7. What is the range of operating temperature?

The electronics are rated for ambient operating temperature of -20°C to 85°C (-4°F to 185°F). The temperature of the media (fluid) could be -20°C to 120°C (-4°F to 248°F).

8. Is waterproof and dustproof?

Yes. The transmitter housing is IP65-rated to IEC standard. It is completely dustproof and water-tight to low-pressure jets from any direction and can be utilized in wash-down or out-of-doors applications.

9. How do I calibrate or test this transmitter?

The transmitter is already pre-calibrated to the range you purchase. Check the output using a multimeter. The output should be 4mA at atmospheric pressure (0 PSI). The output should be 20mA at maximum-rated pressure (for instance, 1000 PSI). Calibration drifts require special equipment and are typically not done in the field.

10. What kind of warranty and support do I get?

We stand behind the quality of our products with confidence. The PT100 WZP-231 is warranted by the manufacturer to be free from defects in materials and workmanship for a normal [e.g., 2-Year or 3-Year] period. Selection and troubleshooting assistance are available from our technical support group.
